Milling Cutters

Long Series Type E431T.Used for profile milling and producing open slots. Bright finish. Flute type: 30° helix.Manufactured to BS 122 : Part 4 : 1980.METRIC TOLERANCES:Diameter: up to 38.00mm. Tolerance: +0.0630, -0.0130.Diameter: Over 38.00mm...

Regular Series Type 5321T.Bright finish. Flute type: 30° helix. Manufactured to BS 122: Part 4: 1980.Metric Tolerances:Diameter: up to 38.00mm. Tolerance: +0.0630, -0.0130.Diameter: Over 38.00mm. Tolerance: +0.1250, -0.0000. • Shank...

Regular Length.Non-centre cutting, used for profile milling, milling keyways and producing open slots. Surface treatment: bright finish. Flute type: 30° Helix. Overall dimensions to DIN 844. Plain shank to DIN 1835A. • Cutter...

Short Series S210T - Metric.Used for milling keyways and slots. Bright finish. Flute type: 30° helix. Manufactured to BS 122: Part 4: 1980.METRIC TOLERANCES:Diameter: ~ up to 3.00. Tolerance: +0.013 -0.033.Diameter: Over 3.00 ~ up to 6.00...

Short Series E410T.Used for profile milling and producing open slots. Bright finish. Flute type : 30° helix.Manufactured to BS 122 : Part 4 : 1980.METRIC TOLERANCES:Diameter: up to 38.00mm. Tolerance: +0.0630, -0.0130.Diameter: Over 38.00mm ~...

Metric Sizes.Designed to produce convex corner radii. For milling structural, carburizing and heat treated steel up to 900N/mm2. Manufactured to works standards. 5° RH Flutes.Bright finish, straight helix. Radii tolerance: ± 0.005". Shank to...

Short Series Type B210T.Used for die sinking, slot milling and profile milling. Bright finish. Flute type: 30° helix.Manufactured to BS 122 : Part 4 : 1980.Metric Tolerances:Diameter: ~ up to 3.00. Tolerance: +0.013 -0.033;Diameter: Over 3.00 ~ up to...

Long Series 5230T.Used for milling keyways and slots. Bright finish. Flute type: 30° helix. Manufactured to BS 122: Part 4: 1980.METRIC TOLERANCES:Diameter: ~ up to 3.00. Tolerance: +0.013 -0.033;Diameter: Over 3.00 ~ up to 6.00. Tolerance:+ 0.020...

Long Series E430T.Used for profile milling and producing open slots. Bright finish. Flute type: 30° helix. Manufactured to BS 122 : Part 4 : 1980.Metric Tolerances:Diameter: up to 38.00. Tolerance: +0.0630, -0.0130.Diameter: Over 38.00. Tolerance: +0...

Long Series Type B230T.Used for diesinking, slot milling and profile milling. Bright finish. Flute type: 30 helix. Manufactured to BS 122 : Part 4 : 1980.Metric Tolerances:Diameter: ~ up to 3.00. Tolerance: +0.013 -0.033;Diameter: Over 3.00 ~ up to 6.00...

Short Series - Metric.Bright finish. Flute type: 30° helix. Manufactured to BS 122: Part 4: 1980.Inch Tolerances:Diameter: ~ up to 1/2". Tolerance: +0.0005, -0.0013.Diameter: Over 1/2". Tolerance:+0.0005, -0.0015. • Shank...

Short Series S210T.Used for milling keyways and slots. Bright finish. Flute type: 30° helix. Manufactured to BS 122: Part 4: 1980.INCH TOLERANCES:Diameter: up to 1/2". Tolerance: +0.0630, -0.0013.Diameter:Over 1/2". Tolerance: +0.1250, -0.0015...

Short Series E410T.Used for profile milling and producing open slots. Bright finish. Flute type : 30° helix.Manufactured to BS 122 : Part 4 : 1980.INCH TOLERANCES:Diameter: up to 1/2". Tolerance: +0.0025, -0.0005.Diameter: Over 1/2" ~. Tolerance: +0...

Long Series E430T.Used for profile milling and producing open slots. Bright finish. Flute type: 30° helix. Manufactured to BS 122 : Part 4 : 1980.Inch Tolerances:Diameter: up to 1/2". Tolerance: +0.0025, 0.0005.Diameter: Over 1/2". Tolerance: +0...

Short Series S210T.Used for milling keyways and slots. Bright finish. Flute type: 30° helix. Manufactured to BS 122: Part 4: 1980.INCH TOLERANCES:Diameter: up to 1/2". Tolerance: +0.0630, -0.0013.Diameter:Over 1/2". Tolerance: +0.1250, -0.0015...

Short Series E410T.Used for profile milling and producing open slots. Bright finish. Flute type : 30° helix.Manufactured to BS 122 : Part 4 : 1980.INCH TOLERANCES:Diameter: up to 1/2". Tolerance: +0.0025, -0.0005.Diameter: Over 1/2" ~. Tolerance: +0...

Long Series 5230T.Used for milling keyways and slots. Bright finish. Flute type: 30° helix. Manufactured to BS 122: Part 4: 1980.Inch Tolerances:Diameter: up to 1/2". Tolerance: +0.0005, -0.0013.Diameter: Over 1/2". Tolerance: +0.0005, -0.0015...

Regular Series Type 5321T.Bright finish. Flute type: 30° helix. Manufactured to BS 122: Part 4: 1980.Inch Tolerances:Diameter: up to 1". Tolerance: +0.0025, -0.0005.Diameter: Over 1". Tolerance: +0.0050, -0.0000. • Shank Diameter...

Short Series S210T.Used for milling keyways and slots. Bright finish. Flute type: 30° helix. Manufactured to BS 122: Part 4: 1980.INCH TOLERANCES:Diameter: up to 1/2". Tolerance: +0.0630, -0.0013.Diameter:Over 1/2". Tolerance: +0.1250, -0.0015...

Short Series E410T.Used for profile milling and producing open slots. Bright finish. Flute type : 30° helix.Manufactured to BS 122 : Part 4 : 1980.INCH TOLERANCES:Diameter: up to 1/2". Tolerance: +0.0025, -0.0005.Diameter: Over 1/2" ~. Tolerance: +0...

Long Series 5230T.Used for milling keyways and slots. Bright finish. Flute type: 30° helix. Manufactured to BS 122: Part 4: 1980.Inch Tolerances:Diameter: up to 1/2". Tolerance: +0.0005, -0.0013.Diameter: Over 1/2". Tolerance: +0.0005, -0.0015...

Long Series E430T.Used for profile milling and producing open slots. Bright finish. Flute type: 30° helix. Manufactured to BS 122 : Part 4 : 1980.Inch Tolerances:Diameter: up to 1/2". Tolerance: +0.0025, 0.0005.Diameter: Over 1/2". Tolerance: +0...

Short Series - Metric.Bright finish. Flute type: 30° helix. Manufactured to BS 122: Part 4: 1980.METRIC TOLERANCES:Diameter: ~ up to 3.00. Tolerance: +0.013 -0.033.Diameter: Over 3.00 ~ up to 6.00. Tolerance:+ 0.020 -0.038.Diameter: Over 6.00 ~ up to...

Short Series S210T - Metric.Used for milling keyways and slots. Bright finish. Flute type: 30° helix. Manufactured to BS 122: Part 4: 1980.METRIC TOLERANCES:Diameter: ~ up to 3.00. Tolerance: +0.013 -0.033.Diameter: Over 3.00 ~ up to 6.00...

Short Series E410T.Used for profile milling and producing open slots. Bright finish. Flute type : 30° helix.Manufactured to BS 122 : Part 4 : 1980.METRIC TOLERANCES:Diameter: up to 38.00mm. Tolerance: +0.0630, -0.0130.Diameter: Over 38.00mm ~...

Long Series 5230T.Used for milling keyways and slots. Bright finish. Flute type: 30° helix. Manufactured to BS 122: Part 4: 1980.METRIC TOLERANCES:Diameter: ~ up to 3.00. Tolerance: +0.013 -0.033;Diameter: Over 3.00 ~ up to 6.00. Tolerance:+ 0.020...

Regular SeriesFor optimum performance and maximum swarf removal when plunging, slotting and routing in light alloys, brass, aluminium, non-ferrous and other soft materials. Manufactured to USCTi Standards. Available in 2 flute for maximum swarf...

Regular SeriesFor optimum performance and maximum swarf removal when plunging, slotting and routing in most materials including brass, aluminium, non-ferrous and other soft materials. Manufactured to USCTi Standards.Metric TolerancesDiameter: Over 1.00 ~...

Short Series - Metric.Bright finish. Flute type: 30° helix. Manufactured to BS 122: Part 4: 1980.METRIC TOLERANCES:Diameter: ~ up to 3.00. Tolerance: +0.013 -0.033.Diameter: Over 3.00 ~ up to 6.00. Tolerance:+ 0.020 -0.038.Diameter: Over 6.00 ~ up to...

Regular Series Type E411T.Used for profile milling and producing open slots. Bright finish. Flute type : 30° helix.Manufactured to BS 122 : Part 4 : 1980.Metric Tolerances:Diameter: up to 38.00mm. Tolerance: +0.0630, -0.0130.Diameter: Over 38.00mm...

Long Series Type E431T.Used for profile milling and producing open slots. Bright finish. Flute type: 30° helix.Manufactured to BS 122 : Part 4 : 1980.METRIC TOLERANCES:Diameter: up to 38.00mm. Tolerance: +0.0630, -0.0130.Diameter: Over 38.00mm...

Regular Series Type 5321T.Bright finish. Flute type: 30° helix. Manufactured to BS 122: Part 4: 1980.Metric Tolerances:Diameter: up to 38.00mm. Tolerance: +0.0630, -0.0130.Diameter: Over 38.00mm. Tolerance: +0.1250, -0.0000. • Shank...

Long Series.Non-centre cutting, used for profile milling, milling keyways and producing open slots. Surface treatment: bright finish. Flute type: 30° Helix. Overall dimensions to DIN 844. Plain shank to DIN 1835A.

Short Series S210T - Metric.Used for milling keyways and slots. Bright finish. Flute type: 30° helix. Manufactured to BS 122: Part 4: 1980.METRIC TOLERANCES:Diameter: ~ up to 3.00. Tolerance: +0.013 -0.033.Diameter: Over 3.00 ~ up to 6.00...

Metric Sizes.Designed to produce convex corner radii. For milling structural, carburizing and heat treated steel up to 900N/mm2. Manufactured to works standards. 5° RH Flutes.Bright finish, straight helix. Radii tolerance: ± 0.005". Shank to...

Short Series Type B210T.Used for die sinking, slot milling and profile milling. Bright finish. Flute type: 30° helix.Manufactured to BS 122 : Part 4 : 1980.Metric Tolerances:Diameter: ~ up to 3.00. Tolerance: +0.013 -0.033;Diameter: Over 3.00 ~ up to...

Long Series 5230T.Used for milling keyways and slots. Bright finish. Flute type: 30° helix. Manufactured to BS 122: Part 4: 1980.METRIC TOLERANCES:Diameter: ~ up to 3.00. Tolerance: +0.013 -0.033;Diameter: Over 3.00 ~ up to 6.00. Tolerance:+ 0.020...

Long Series E430T.Used for profile milling and producing open slots. Bright finish. Flute type: 30° helix. Manufactured to BS 122 : Part 4 : 1980.Metric Tolerances:Diameter: up to 38.00. Tolerance: +0.0630, -0.0130.Diameter: Over 38.00. Tolerance: +0...

Short Series S210T - Metric.Used for milling keyways and slots. Bright finish. Flute type: 30° helix. Manufactured to BS 122: Part 4: 1980.METRIC TOLERANCES:Diameter: ~ up to 3.00. Tolerance: +0.013 -0.033.Diameter: Over 3.00 ~ up to 6.00...

Short Series E410T.Used for profile milling and producing open slots. Bright finish. Flute type : 30° helix.Manufactured to BS 122 : Part 4 : 1980.METRIC TOLERANCES:Diameter: up to 38.00mm. Tolerance: +0.0630, -0.0130.Diameter: Over 38.00mm ~...
